Description
Models and Ratings
| Model | Input | Rated Input | Capacity | Charge Voltage | Electrode Max Pressure | Stroke | Throat Dimensions | Electrode Size | Weight | Welding Capacity |
| Phase/Hz | kVA | Ws | V | kN | mm | (W x D)mm | mm | kg | mm x pcs | |
| YG-101SPF/101SPA | 1ф 50/60Hz |
0.6 | 100 | Low (70~270)High (260~460) |
0.15 | 13 | 35 x 105 | ф6 x 56 | 41 | 0.3 x 2 |
| YG-501SPF/501SPA | 3.0 | 500 | 0.49 | 20 | 85 x 120 | ф8 x 30ℓ Taper 1/10 |
102 | 0.5 x 2 |
Dimensions
| Model | W (mm) | D (mm) | H (mm) | Weight | |
| YG-101SPF(SPA) | Power Source | 222 (372) | 470 | 340 | 37 |
| Welding Head | 40 (51) | 165 | 281 (350) | 3.8 | |
| YG-501SPF(SPA) | Power Source | 272 (422) | 424 | 393 | 40 |
| Transformer | 223 | 420 | 394 | 50 | |
| Welding Head | 70 | 232 | 455 (523) | 9 | |
